Woolich Racing Products

Tuning Shop Packages
Woolich Racing Tuned Software

Select the Manufacturer, Model and Year.

Filters

Manufacturer
Model
Year
Complete packages with Interface, Harness and Bin File Definitions
Product Description Price
2008-2016 Kawasaki ZRX1200 - USB (Mitsubishi) v3 Package
2008-2016 Kawasaki ZRX1200 - USB (Mitsubishi) v3 Package 2008-2016 Kawasaki ZRX1200 - USB (Mitsubishi) v3 Package
This package includes everything you need to start tuning your 2008-2016 Kawasaki ZRX1200 with our USB (Mitsubishi) and On Bike Harness.
  • USB (Mitsubishi) v3
  • Kawasaki Type 2 On Bike Harness
  • USB Cable
  • Bin File Definition in the Woolich Racing Tuned software
US$408.00
ex Sales Tax VAT
More Details

This product comes with 1 Bin File Definition Key allowing you to tune 1 ECU's as many times as you like. Additional Bin File Definition Keys are required for each additional ECU's and can be purchased from within the WRT software.
Bin File Definitions - for use in Woolich Racing Tuned software
Product Description Price
2008-2016 ZRX1200 Bin File Definition
2008-2016 ZRX1200 Bin File Definition
Purchase this item to gain access in the Woolich Racing Tuned software to the stock bin files for the 2008-2016 Kawasaki ZRX1200



Note: The WRT software is only available to verified Woolich accounts. We only verify customer accounts that have purchased the necessary products (Woolich Log Box or USB interface, along with the appropriate harness and -if required- a bin file definition key) to flash their ECU. Accounts with no purchases of the required products can not be verified.
US$ 105.00
ex Sales Tax VAT
More Details

   Features available for Kawasaki ZRX1200 2008-2016
  • IAP Fuel Maps
  • TPS Fuel Maps
  • Ignition Timing Maps
  • Secondary Throttle Plate (STP) Opening Maps
  • RPM Limiter
  • Fan Temperature
  • Engine Data - View Live Engine Data
  • Woolich Racing AutoTune - (Requires Applicable LogBox + Zeitronix Package)

ECU Part Numbers:
  • 21175-0201
  • 21175-0709

This product comes with 1 Bin File Definition Key allowing you to tune 1 ECU's as many times as you like. Additional Bin File Definition Keys are required for each additional ECU's and can be purchased from within the WRT software.
Harnesses
Product Description Price
Barrel to 2 Pin Plug Bench Harness Power Supply Connector
Barrel to 2 Pin Plug Bench Harness Power Supply Connector
This harness allows you to connect the 2 pin plug used on our Bench Harnesses to a 12v Power Supply with a standard 2.5mm barrel connector.
US$10.00
ex Sales Tax VAT
More Details
Kawasaki Harness Type 2 (KH2/5/6)
Kawasaki Harness Type 2 (KH2/5/6)
The Kawasaki Harness Type 2 allows you to connect a Woolich Racing Mitsubishi USB Interface to the bike harness allowing the ECU to be flashed while still in the bike connected to the harness.
US$42.00
ex Sales Tax VAT
More Details
Kawasaki Extension Harness Type 2 (KEH2/5)
Kawasaki Extension Harness Type 2 (KEH2/5)
The Kawasaki Extension Harness Type 2 is required on some 2010 ZX10R bikes that do not have the 2nd KDS plug on the main bike harness.

If you are purchasing a Kawasaki Harness Type 2 for a 2010 ZX10R please check to ensure that both KDS style plugs are available on the harness. If you are unable to find the 2nd KDS plug you will need to purchase this item.
US$16.00
ex Sales Tax VAT
More Details
Kawasaki Bench Harness Type 2 (KBH2)
Kawasaki Bench Harness Type 2 (KBH2)
The bench flashing harness allows you to flash 2008-2010 ZX10R and ZRX1200 ECU when they are not installed in the bike. The bench flashing harness comes with a 12v plug and needs to be used in conjunction with the Woolich Racing Mitsubishi USB Interface.

Note: this product requires the purchase of Bin Files for use with the Woolich Racing Tuned software
US$101.00
ex Sales Tax VAT
More Details
