Woolich Racing Products

Tuning Shop Packages
Woolich Racing Tuned Software

Select the Manufacturer, Model and Year.

Filters

Manufacturer
Model
Year
Complete packages with Interface, Harness and Bin File Definitions
Product Description Price
2004-2006 Kawasaki ZX12R - USB D v3 Package
2004-2006 Kawasaki ZX12R - USB D v3 Package 2004-2006 Kawasaki ZX12R - USB D v3 Package
This package includes everything you need to start tuning your 2004-2006 Kawasaki ZX12R with our USB D v3 and On Bike Harness.
  • USB D v3
  • Kawasaki Harness Type 14a
  • USB Cable
  • Bin File Definition in the Woolich Racing Tuned software.
US$408.00
ex Sales Tax VAT
More Details

This product comes with 1 Bin File Definition Key allowing you to tune 1 ECU's as many times as you like. Additional Bin File Definition Keys are required for each additional ECU's and can be purchased from within the WRT software.
2004-2006 Kawasaki ZX12R - Log Box D v3 - Zeitronix ZT-3 Wideband O2 Package
2004-2006 Kawasaki ZX12R - Log Box D v3 + Zeitronix ZT-3 Wideband O2 Package 2004-2006 Kawasaki ZX12R - Log Box D v3 + Zeitronix ZT-3 Wideband O2 Package 2004-2006 Kawasaki ZX12R - Log Box D v3 + Zeitronix ZT-3 Wideband O2 Package
This package includes everything you need to start tuning your 2004-2006 Kawasaki ZX12R with our Log Box D v3 and Zeitronix ZT-3 Wideband O2 Sensor.
  • Log Box D v3
  • USB Cable
  • On board 4GB micro SD card
  • Zeitronix ZT-3 Wideband O2 Controller
  • Zeitronix Wideband O2 Sensor (3 foot cable)
  • RJ12 cable to connect Zeitronix to Log Box
  • Zeitronix Installation Kit (12v relay, wires, wideband O2 bung and connectors etc)
  • Kawasaki Harness Type 14a
  • Bin File Definitions in Woolich Racing Tuned Software
US$788.00
ex Sales Tax VAT
More Details

This product comes with 1 Bin File Definition Key allowing you to tune 1 ECU's as many times as you like. Additional Bin File Definition Keys are required for each additional ECU's and can be purchased from within the WRT software.
Bin File Definitions - for use in Woolich Racing Tuned software
Product Description Price
2004-2006 ZX12R Bin File Definition
2004-2006 ZX12R Bin File Definition
Purchase this item to gain access in the Woolich Racing Tuned software to the stock bin files for the 2004-2006 Kawasaki ZX12R



Note: The WRT software is only available to verified Woolich accounts. We only verify customer accounts that have purchased the necessary products (Woolich Log Box or USB interface, along with the appropriate harness and -if required- a bin file definition key) to flash their ECU. Accounts with no purchases of the required products can not be verified.
US$ 105.00
ex Sales Tax VAT
More Details

   Features available for Kawasaki ZX12R 2004-2006
  • IAP Fuel Maps
  • TPS Fuel Maps
  • Ignition Timing Maps
  • Ignition Dwell Map/s
  • Secondary Throttle Plate (STP) Opening Maps
  • RPM Limiter
  • Disable Top Speed Limiter
  • ECU Mode
  • Engine Data - View Live Engine Data
  • Woolich Racing AutoTune - (Requires Applicable LogBox + Zeitronix Package)
  • Diagnostics: Read and Clear Fault Codes - (Requires Applicable V3 Interface)

ECU Part Numbers:
  • 21175-0028
  • 21175-0036
  • 21175-0037
  • 21175-0038
Harnesses
Product Description Price
Kawasaki Harness Type 14a (KH14A-KEH14A/14B)
Kawasaki Harness Type 14a (KH14A + KEH14A/14B)
On Bike Harness to connect USB Interface to applicable Kawasaki bikes enabling both ECU Flashing and Engine Data.
Includes:
  • Kawasaki Type 14a Main Harness
  • Kawasaki Extension Harness Type 14a
US$42.00
ex Sales Tax VAT
More Details
Barrel to 2 Pin Plug Bench Harness Power Supply Connector
Barrel to 2 Pin Plug Bench Harness Power Supply Connector
This harness allows you to connect the 2 pin plug used on our Bench Harnesses to a 12v Power Supply with a standard 2.5mm barrel connector.
US$10.00
ex Sales Tax VAT
More Details
Kawasaki Bench Harness Type 15 (KBH15)
Kawasaki Bench Harness Type 15 (KBH15)
The bench flashing harness allows you to flash 2004-2006 ZX12R  ECUs when they are on the bench not installed in the bik. The bench flashing harness comes with a 12v plug and needs to be used in conjunction with the Woolich Racing USB Interface.

Note: this product requires the purchase of an Interface and Bin File for use with the Woolich Racing Tuned software
US$101.00
ex Sales Tax VAT
More Details
Kawasaki Extension Harness Type 14A/14B (KEH14A/14B)
Kawasaki Extension Harness Type 14A/14B (KEH14A/14B)
Extension Harness for Kawasaki Harness Type 14. This is the part of the Kawasaki Type 14 Harness that remains on the bike.
Includes:
  • Kawasaki Extension Harness Type 14
US$21.00
ex Sales Tax VAT
More Details
