Complete packages with Interface, Harness and Bin File Definitions
Product Description Price
2011-2025 Suzuki M109R - USB D v3 Package
2011-2025 Suzuki M109R - USB D v3 Package 2011-2025 Suzuki M109R - USB D v3 Package
This package includes everything you need to start tuning your 2011-2025 Suzuki M109R with our USB Interface.
  • USB D v3
  • Suzuki Type 2c Harness
  • USB Cable
  • Bin File Definitions in the Woolich Racing Tuned software
US$414.00
ex Sales Tax VAT
More Details
Race Tools: Quickshifter, Launch Control, Pit Speed Limiter
Product Description Price
2011-2025 Suzuki M109R Launch Control Key
Launch Control is part of the our Race Tools Package. It allows you to set a Launch RPM and also Ramp Parameters to assist with getting fast consistent launches from your bike, all controlled by the stock ECU.

If you already have a Quickshifter or Air Shifter installed on your bike or you only need the Launch Control function you can purchase this Launch Control Key. The Launch Control Key allows you to enable the Launch Control for one ECU.
Woolich Racing Race Tools requires you to Write the ECU. It is not a stand alone product. You will need to use the relevant Woolich Racing Interface and Bin File Definition to enable and configure Race Tools and write to the ECU. You can purchase this as a package on the product page for your bike. If you do not have a Woolich Racing Interface you can also visit a Woolich Racing - Tuning Partner and have them install and configure the Race Tools (additional fees and charges will apply).
US$210.00
ex Sales Tax VAT
More Details
2011-2025 Suzuki M109R Race Tools Package
2011-2025 Suzuki M109R Race Tools Package

The Race Tools package allows you to enable Quickshifter, Launch Control and Pit Speed Limiter in the Stock ECU.

The package includes:

  • High quality strain gauge Quickshifter with digitally controlled pressure sensing that can be used in regular or race shift pattern.
  • Shift rod for standard shift configuration*
  • Suzuki Race Tools Harness Type 1 which allows the quickshifter to be plugged into the bikes wiring harness**
  • Race Tools Key to allow the use of the Race Tools on one ECU in the Woolich Racing Tuned software.

Quickshifter Kill times are configurable per gear with 3D maps allowing Kill Times to be set for the full range of TPS and RPM combinations. The quickshifter kills both fuel and ignition.

Launch Control allows you to configure Delay, Launch RPM, Ramp Time and Ramp RPM

Pit Speed Limiter allows you to set the RPM to limit the speed while riding through the pits.***

* Contact us after ordering if you have after-market rearsets or are using a race shift pattern and we will swap the shift rod for a generic rod that can be cut and tapped to the correct length.

** This harness uses the stock Exhaust Valve plugs on the bike's harness, the stock Exhaust Valve should be removed from the bike and disabled in our software

*** Pit Speed Limiter harness sold separately


Woolich Racing Race Tools requires you to Write the ECU. It is not a stand alone product. You will need to use the relevant Woolich Racing Interface and Bin File Definition to enable and configure Race Tools and write to the ECU. You can purchase this as a package on the product page for your bike. If you do not have a Woolich Racing Interface you can also visit a Woolich Racing - Tuning Partner and have them install and configure the Race Tools (additional fees and charges will apply).
US$494.00
ex Sales Tax VAT
More Details
Pit Speed Limiter Harness
Pit Speed Limiter Harness
The Pit Speed Limiter harness is used with our Race Tools Package, it consists of a harness and water proof push button switch which allows you to limit the RPM of the bike in 1st gear while riding in the pits. You must have a Race Tool Package to use the Pit Speed Limiter Harness.

The Pit Speed Limiter harness also includes a stainless steel bracket used to mount the button on the bike's switch gear.

Woolich Racing Race Tools requires you to Write the ECU. It is not a stand alone product. You will need to use the relevant Woolich Racing Interface and Bin File Definition to enable and configure Race Tools and write to the ECU. You can purchase this as a package on the product page for your bike. If you do not have a Woolich Racing Interface you can also visit a Woolich Racing - Tuning Partner and have them install and configure the Race Tools (additional fees and charges will apply).
US$26.00
ex Sales Tax VAT
More Details
Bin File Definitions - for use in Woolich Racing Tuned software
Product Description Price
2011-2025 M109R Stock Bin File Definitions
2011-2025 M109R Stock Bin File Definitions
Purchase this item to gain access in the Woolich Racing Tuned software to the stock bin files for the 2011-2025 Suzuki M109R



Note: The WRT software is only available to verified Woolich accounts. We only verify customer accounts that have purchased the necessary products (Woolich Log Box or USB interface, along with the appropriate harness and -if required- a bin file definition key) to flash their ECU. Accounts with no purchases of the required products can not be verified.
US$ 105.00
ex Sales Tax VAT
More Details

   Features available for Suzuki M109R 2011-2025
  • IAP Fuel Maps
  • TPS Fuel Maps
  • Ignition Timing Maps
  • Secondary Throttle Plate (STP) Opening Maps
  • RPM Limiter
  • Disable Stock O2 Sensor
  • ECU Mode
  • Engine Data - View Live Engine Data
  • Diagnostics: Read and Clear Fault Codes - (Requires Applicable V3 Interface)

ECU Part Numbers:
  • 32920-48GA0
  • 32920-48GA1
  • 32920-48GB0
  • 32920-48GB1
  • 32920-48GC0
  • 32920-48GC1
  • 32920-48GD0
  • 32920-48GD1
  • 32920-48GG0
  • 32920-48GH0
  • 32920-48GH1
  • 32920-48GJ0
  • 32920-48GK0
  • 32920-48GK1
  • 32920-48GN0
  • 32920-48GP0

This product comes with 1 Bin File Definition Key allowing you to tune 1 ECU's as many times as you like. Additional Bin File Definition Keys are required for each additional ECU's and can be purchased from within the WRT software.
Harnesses
Product Description Price
Extension Harness Long
Extension Harness Long
The Extension Harness - Long is a 8 pin Molex (male) to 8 Pin Molex (female) entension harness 1100mm long that allows you to extend the length of all Woolich Racing Harnesses.
US$32.00
ex Sales Tax VAT
More Details
Extension Harness Short
Extension Harness Short
The Extension Harness - Short is a 8 pin Molex (male) to 8 Pin Molex (female) extension harness 600mm long that allows you to extend the length of all Woolich Racing Harnesses.
US$21.00
ex Sales Tax VAT
More Details
Suzuki Harness Type 2c (SH2A/2C/3-SEH2C-O/Y 2 WIRE)
Suzuki Harness Type 2c (SH2A/2C/3 + SEH2C + O/Y 2 WIRE)
On Bike Harness includes:
  • Suzuki Type 2 Main Harness
  • 2wire harness (yellow/orange)
  • 2 wire harness (blue/green)
  • Yosh Plug
US$47.00
ex Sales Tax VAT
More Details
Suzuki Extension Harness Type 2c (SEH2C-O/Y 2 WIRE)
Suzuki Extension Harness Type 2c (SEH2C + O/Y 2 WIRE)
Extension harness to be used with Suzuki Harness Type 2c, allows additional bikes to be tuned.
Includes:
  • 2 wire harness (Yosh Box Plug)
  • 2 wire harness (SDS Plug)
US$21.00
ex Sales Tax VAT
More Details
Suzuki Harness Type 2a (SH2A/2C/3-O/Y 2 WIRE-B/G 2 WIRE)
Suzuki Harness Type 2a (SH2A/2C/3 + O/Y 2 WIRE + B/G 2 WIRE)
On Bike Harness includes:
  • Suzuki Type 2 Main Harness
  • 2wire harness (Yosh Box)
  • 2 wire harness (SDS Plug)
US$42.00
ex Sales Tax VAT
More Details
Barrel to 2 Pin Plug Bench Harness Power Supply Connector
Barrel to 2 Pin Plug Bench Harness Power Supply Connector
This harness allows you to connect the 2 pin plug used on our Bench Harnesses to a 12v Power Supply with a standard 2.5mm barrel connector.
US$10.00
ex Sales Tax VAT
More Details
Suzuki Dealer Mode Harness Type 1
Suzuki Dealer Mode Harness Type 1
The Suzuki Dealer Mode Harness plugs into the bikes diagnostic plug. When you turn the ignition on with the harness installed you will be able to see fault codes and access dealer menu's on the dash. The features available vary with model.


Compatible with the following models:

Suzuki C109 Boulevard/C109 Intruder 2008-2011
Suzuki C90 Boulevard/VL 1500 Intruder 2005-2015
Suzuki GSF 1250 (Bandit) 2007-2016
Suzuki GSF 650 (Bandit) 2008-2012
Suzuki GSR 400 2006-2009
Suzuki GSR 600 2006-2010
Suzuki GSR 750 2011-2017
Suzuki GSX 1400 2004-2008
Suzuki GSX1300BK (B-King)2007-2012
Suzuki GSX1300R (Hayabusa)2008-2020
Suzuki GSX-R 1000 2003-2024
Suzuki GSX-R 1000 EM-Pro Race Kit ECU 2020
Suzuki GSX-R 1000R 2017-2024
Suzuki GSX-R 600 2004-2024
Suzuki GSX-R 750 2004-2024
Suzuki GSX-S 1000 2015-2020
Suzuki GSX-S 1000 Katana 2019-2020
Suzuki GSX-S 750 2015 2020
Suzuki M109R 2006-2020
Suzuki SFV 650 SV 650S (Gladius)2009-2015
Suzuki SV 1000 2005-2008
Suzuki SV 650 2007-2012
US$16.00
ex Sales Tax VAT
More Details
Suzuki Bench Harness Type 2 (SBH2)
Suzuki Bench Harness Type 2 (SBH2)
The bench flashing harness allows you to flash the ECU on the bench when it is not installed in the bike.
US$101.00
ex Sales Tax VAT
More Details
12V Bench Flashing Power Supply with Type A Plug (USA, Canada, Japan)
12V Bench Flashing Power Supply with Type A Plug (USA, Canada, Japan)
This 12V, 1.5A Power Supply (max output 13V) has been designed for use with Woolich Racing Bench Harnesses.

This product comes with an integrated on/off switch and interchangeable Type A plug used in USA, Canada, Japan and Mexico.

Input: 100-240V 50/60Hz
*This power supply is NOT designed to be used as a battery charger.
US$37.00
ex Sales Tax VAT
More Details
12V Bench Flashing Power Supply with Type C plug (Europe, Asia)
12V Bench Flashing Power Supply with Type C plug (Europe, Asia)
This 12V, 1.5A Power Supply (max output 13V) has been designed for use with Woolich Racing Bench Harnesses.

This product comes with an integrated on/off switch and interchangeable Type C plug used in most of Europe, parts of Asia, and parts of South America.

Input: 100-240V 50/60Hz
*This power supply is NOT designed to be used as a battery charger.
US$37.00
ex Sales Tax VAT
More Details
12V Bench Flashing Power Supply with Type I plug (AU, NZ, China)
12V Bench Flashing Power Supply with Type I plug (AU, NZ, China)
This 12V, 1.5A Power Supply (max output 13V) has been designed for use with Woolich Racing Bench Harnesses.

This product comes with an integrated on/off switch and interchangeable Type I plug used in Australia, New Zealand and mainland China.

Input: 100-240V 50/60Hz
*This power supply is NOT designed to be used as a battery charger.

US$37.00
ex Sales Tax VAT
More Details
12V Bench Flashing Power Supply with Type G plug (UK, Malaysia & Singapore)
12V Bench Flashing Power Supply with Type G plug (UK, Malaysia & Singapore)
This 12V, 1.5A Power Supply (max output 13V) has been designed for use with Woolich Racing Bench Harnesses.

This product comes with an integrated on/off switch and interchangeable Type  G plug used in the UK, Ireland, Malaysia & Singapore.

Input: 100-240V 50/60Hz
*This power supply is NOT designed to be used as a battery charger.
US$37.00
ex Sales Tax VAT
More Details
Motorcycle Diagnostics - OBD2
Product Description Price
Suzuki Dealer Mode Harness Type 1
Suzuki Dealer Mode Harness Type 1
The Suzuki Dealer Mode Harness plugs into the bikes diagnostic plug. When you turn the ignition on with the harness installed you will be able to see fault codes and access dealer menu's on the dash. The features available vary with model.


Compatible with the following models:

Suzuki C109 Boulevard/C109 Intruder 2008-2011
Suzuki C90 Boulevard/VL 1500 Intruder 2005-2015
Suzuki GSF 1250 (Bandit) 2007-2016
Suzuki GSF 650 (Bandit) 2008-2012
Suzuki GSR 400 2006-2009
Suzuki GSR 600 2006-2010
Suzuki GSR 750 2011-2017
Suzuki GSX 1400 2004-2008
Suzuki GSX1300BK (B-King)2007-2012
Suzuki GSX1300R (Hayabusa)2008-2020
Suzuki GSX-R 1000 2003-2024
Suzuki GSX-R 1000 EM-Pro Race Kit ECU 2020
Suzuki GSX-R 1000R 2017-2024
Suzuki GSX-R 600 2004-2024
Suzuki GSX-R 750 2004-2024
Suzuki GSX-S 1000 2015-2020
Suzuki GSX-S 1000 Katana 2019-2020
Suzuki GSX-S 750 2015 2020
Suzuki M109R 2006-2020
Suzuki SFV 650 SV 650S (Gladius)2009-2015
Suzuki SV 1000 2005-2008
Suzuki SV 650 2007-2012
US$16.00
ex Sales Tax VAT
More Details
